2.5mm Twill Weave Silicone Fabric 50m Length Heat Resistant Heavy Duty For High Temperature Environments

Brand Name : Yaoxing

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T

Supply Ability : 300000 kilograms per month

Delivery Time : 5-15 work days

Packaging Details : PVC bags

Features : Heat resistant, Flame Retardant, Chemical Resistant

Width : 1.2m

Matreial : Silicone Rubber and Fiberglass

Length : 50m

Usage : Smoke Curtain,Fire Blanket

Surface Treatment : Silicone Rubber Calendering

Working Temperature : -40℃-200℃

Weave Type : Plain Woven,Twill Woven

Contact Now

2.5mm Satin Weave Silicone Fabric Heavy Duty 200°C Resistant


Ⅰ.The properties of the silicone calender cloth are as follows


1. Heat resistant
2. High mechanical strength
3. Anti-ageing
4. Soft and easy to cut
5. High dielectric strength


Ⅱ.Specification with Silicone Coated Glass Fabric:


Type Silicone Coated Fiberglass Cloth
Thickness 0.1 mm-3 mm
Width 1 m, 1.2 m, 1.5 m
Roll length 50m, 100m, 150m, 200m
Knitting type Plain woven/ Twill woven
Glass Yarn Type E-Glass/ C-Glass
Advantages Good Insulation, Heat Resistance
Corrosion Resistance, High Mechanical Strength


Ⅲ.Application


Due to the high dielectric strength and superior breakdown voltage of silicone calender fabric,this silicone fabric can be made into electric insulation mat,electric insulation cover and others,in order to resist the high voltage or offer insulation protection.


Ⅳ. Characteristics


1. Used in temperatures ranging from -40°C to 200°C.

2. Resistant to ozone, oxygen, sunlight and ageing. Long usage life of up to 10 years.

3. High insulating properties: dielectric constant 3-3.2; breaking down voltage: 20-50 KV/mm.

4. Good flexibility and high surface friction.

5. Chemical corrosion resistance


Cushion for pressure lamination


Silicone calender-coated fabric has an excellent smooth and soft surface. It can resist high temperatures and has high mechanical strength.
Compared to a PTFE liner or pillow, which are also used for heat press release, silicone fabric can be used in industry to withstand higher pressure due to the softness of silicone.


2.5mm Twill Weave Silicone Fabric 50m Length Heat Resistant Heavy Duty For High Temperature Environments


2.5mm Twill Weave Silicone Fabric 50m Length Heat Resistant Heavy Duty For High Temperature Environments
